:, and each key gets a grid row with its type, TTL, length, and value. The editor takes Redis commands, one per statement, and passes them through as written. Redis needs no plugin: its hiredis-based driver is part of the app, and it reaches standalone servers, Sentinel-managed primaries, and Redis Cluster.
Quick setup
1
Create Connection
Click Create Connection…, select Redis, and enter host, port, password, and database index
2
Test Connection
Click Test Connection, then Save & Connect
Connection settings
No minimum server version. ACL users need Redis 6, a Sentinel ACL user needs 6.2, and Cluster mode reads routing tips from Redis 7 where they exist.
The sidebar then lists one entry per database,
db0 upward, counted from the server’s own CONFIG GET databases (16 if it does not answer). Click one to browse it in place, which is also how the database index changes after connecting.
Connection URL
rediss:// connects with TLS. See Connection URL Reference.
Connection modes
Standalone
The default. One server, named by Host and Port.Sentinel
For a deployment fronted by Redis Sentinel. The quorum says which node is primary and the data connection opens there; a failover is read from the quorum on the next health check and the connection moves itself. A demoted primary keeps answeringrole:master and keeps accepting writes for several seconds, and those writes are lost, so the quorum is the only signal worth trusting.
Host and Port are ignored here. Username and Password under Authentication belong to the primary; Sentinel is a separate plane with its own. The rest of the quorum is discovered at connect and remembered, so a lookup still works once the node you listed goes down. If none can be reached, or none monitors the group you named, the error lists the addresses tried and the groups they do monitor.
Cluster
For a sharded Redis Cluster. The shard map is read withCLUSTER SHARDS, or CLUSTER SLOTS on Redis 6; a connection opens to every primary and each command goes to the shard that owns its key.
DBSIZE is summed across shards, browsing merges their keys into one tree, and MGET, MSET, DEL, EXISTS, TOUCH and UNLINK are split per shard and recombined. A MOVED re-points the slot and retries, an ASK retries against the importing node, and one command follows at most five redirects. What Cluster mode cannot do is under Limitations.
The wrong mode is caught at connect: Standalone against a cluster member, or any data mode against a Sentinel port, names the field to change.
Amazon ElastiCache (IAM)
Set Authentication to an AWS IAM mode (Access Key, Profile, or SSO). A short-lived IAM token becomes the Redis password and the username is your IAM-enabled Redis user. Enter the AWS region and the cache name (replication group ID), and turn TLS on, which ElastiCache IAM requires. Profiles resolve from~/.aws/config and ~/.aws/credentials, credential_process, SSO, and assumed roles included.
Browsing keys
user:1 and user:2 sit under a user folder, nested as deep as the key goes (app:cache:session:1). Change the separator in Advanced settings.
Keys grouped by namespace with type-aware values
A value that is not valid UTF-8, such as a gzip or MessagePack payload, opens in the hex editor instead of as text.
Editing
Editing a Key cell runsRENAME. Editing a TTL cell runs EXPIRE, or PERSIST when you set it to -1; in that column -1 means no expiry and -2 means the key is gone. Editing a Value cell runs SET, and only on a string, since a preview of a hash or list is not the whole structure.
Change the other types with a command: HSET myhash field1 "value1" rewrites one field and leaves the rest alone. Adding a row does follow the type you pick, generating HSET, RPUSH, SADD, ZADD, or SET.
Filtering
Toggle the filter bar to search keys by pattern. Patterns are Redis glob (* any sequence, ? one character, [ae] a character set) and case-sensitive, as in redis-cli. The type scope narrows to String, Hash, List, Set, Sorted Set, or Stream. Matching runs server-side with SCAN MATCH and SCAN TYPE.
Redis CLI
Each statement is one command; separate several with;. Commands the driver does not recognize go through too, and only the result formatting is type-aware. Arguments are quoted the way redis-cli quotes them, so " and ' both work and \xHH writes a raw byte; unbalanced quotes are rejected rather than guessed at. Redis has no comment syntax and none is stripped, so a -- or # line is sent to the server and fails.
SSL/TLS
Set this in the SSL/TLS pane. Upstash, Redis Cloud and the like require TLS;rediss:// turns it on when importing a URL.
New connections default to Disabled. SNI is sent in every TLS mode.
Limitations
- No transactions in Cluster mode. Grid saves run their statements one at a time. Group keys under one hash tag if they must move together.
- Cluster mode serves database 0 only. The Database Index field is hidden and the sidebar shows a single
db0. - A command whose keys span hash slots, such as
RENAME,SMOVE, or the*STOREcommands, is refused in Cluster mode before it is sent. Give the keys a shared hash tag, like{user}:1and{user}:2. - A key that is not valid UTF-8 never appears in the grid or the tree. Reach it from the CLI; values have no such limit.
- Pub/Sub has no grid support.
PUBLISHruns in the CLI, and there is no subscriber view. - The sidebar tree loads at most 50,000 keys and a filter scans at most 10,000 matches. Narrow the pattern, or
SCANfrom the CLI. - Values and TTLs cannot be filtered on. Redis has no server-side primitive for either; filter by key pattern and type only.
- No import. Export works as it does elsewhere.
Troubleshooting
Connection refused: check Redis is running (brew services start redis), the port matches redis.conf, and the bind directive covers the address you are using.
WRONGPASS invalid username-password pair or user is disabled.: with Username empty, AUTH password is checked against the default user, and an ACL user’s password fails that. Fill in Username to authenticate as that user.
One ACL trap produces the same error: >password sets a password, #hash sets a SHA-256 hash, and a 64-character hex string is valid for both, so ACL SETUSER myuser on #<64-hex> is accepted where > was meant. ACL LIST prints passwords as hashes, so a value copied from there is a hash, not a password.
Timeout: verify host and port, check the network and firewall, and allow your IP on a cloud-hosted Redis.
Sentinel or Cluster over SSH: a tunnel forwards one local port to one remote address, and the addresses Sentinel and Cluster hand back are the server’s own. Over a tunnel only the first host in the list is used, as a standalone node, so failover and shard routing are unavailable.
Slow key list: KEYS blocks the server on a large keyspace. Browse by namespace instead, and use SCAN in the CLI when you need a pattern. Check memory pressure with INFO memory.
